"paymentMethodName": "UzumBankApp"

Payment Method Features

Payment Method	UzumBankApp
Country	Uzbekistan
Processing Currencies	UZS
Payments	Yes
-- Min per transaction amount	500 UZS
-- Max per transaction amount	999,999,999 UZS
-- Authentication	None
Disbursements	No
Refunds	Full, via Support only (no API)
Chargebacks	No

Possible Payment Scenarios:

Our API will provide you with all the necessary information to execute the following scenario:

Steps
The payer initiates the payment You create an Intent Our Platform returns a payment link (a link that leads a user to the banking app). The payer proceeds to the link and confirms the payment Our Platform processes the payment Our Platform returns you the final payment status via a callback

Workflow Overview:

High-resolution image is available on the link: (UzumApp-Payments)

[Step 1.3] You need to create a new intent

Use the following API method to create an intent: POST /processing/api/v1/intents.
When creating the intent, complete the Payment object.

Request Example

{
  "clientReferenceId": "123456789",
  "payments": [
    {
      "paymentInstrument": {
        "paymentMethodName": "UzumBankApp"
      },
      "submittedAmount": {
        "value": 100,
        "currency": "UZS"
      },
      "authCurrencyCode": "UZS"
    }
  ]
}

Request fields description

Field	Required	Type	Description	Example
clientReferenceId	Required	String	The client/merchant intent reference. Aka, Transaction Reference	1234
payments	Required	Array of objects		--

Object "payment" fields description:

Field	Required	Type	Description	Example
paymentInstrument	Required	Object	The receiver payment instrument	n/a
submittedAmount	Required	Object		n/a
authCurrencyCode	Required	String	The currency the transaction will be processed. Always UZS for this method	UZS

Object "payments[].paymentInstrument" fields description:

Field	Required	Type	Description	Example
paymentMethodName	Required	String	Payment method name	UzumBankApp

Object "payments[].submittedAmount" fields description:

Field	Required	Type	Description	Example
value	Required	Number	Transaction amount	100.40
currency	Required	String	The original currency of the transaction. Can vary, will be converted into auth currency during the processing	USD

[Step 1.6] Return the generated link to the App

In the response for the Intent creation you will receive the link in the specific format
Link format: https://www.uzumbank.uz/open-service?serviceId=123422111&amount=100000&order_id=243083314944495600

Attribute	Description	Example
serviceId	Service Id of you or your client in the processor's system	123422111
amount	An amount you provided us but in	Payment amount in tiyin (the smallest currency unit)
order_id	Payment ID in our system	243083314944495600

You need to provide this link to the payer in any convenient way

[Step 3.5] Payer Confirmed the payment in the App: You will receive the latest Payment Authorisation Status

You will receive the transaction status via the webhook
More about payment webhooks on the separate page

Webhook Example

    {
      "status": "AUTHORIZED",
      "errorCode": "CODE_PT0000",
      "errorMessage": "string"
    }

Test Data

Our system allows emulating different test cases in the sandbox environment. To simulate specific scenarios and receive different results, use the intent.description parameter.

SBP Payment Test flow

High-resolution image is available on the link: UzumBankApp_TestFlow.jpg

Case	intent.description	final paymentStatus
Successful payment	--	CAPTURED
Payment Declined	DeclinedPayment	DECLINED
Failure	LinkCreationError	ERROR

Case "Successful payment"

Steps:

The client creates an intent via POST /processing/api/v1/intents.
A synchronous response is returned with paymentStatus = AUTHORIZATION_REQUESTED.
The client follows the link from payments.additionalData.details.url.
A callback is received with paymentStatus = CAPTURED.

Case "Payment Declined"

Steps:

The client creates an intent viaPOST /processing/api/v1/intents using the intent.description parameter with the value "DeclinedPayment".
A synchronous response is returned with paymentStatus = AUTHORIZATION_REQUESTED.
The client follows the link from payments.additionalData.details.url.
A callback is received with paymentStatus = DECLINED.

Case "Failure"

Steps:

The client creates an intent viaPOST /processing/api/v1/intents using the intent.description parameter with the value "LinkCreationError".
A synchronous response is returned with paymentStatus = ERROR.
